Data Transfer Between Simulation Software and Injection Molding Machine
ENGEL sim link Combines Simulation and Real Production
The two-way interface sim link enables data exchange between the simulation software and the injection molding machine. This saves a great deal of time between mold development and production and reduces the risk of a delayed production start. In addition, you reduce the sampling time to an absolute minimum.
The Advantages of sim link at a Glance
The bonus of the data transfer between simulation software and injection molding machine: sim link offers the possibility to consider the dynamics of the machine selected for production. This allows you to decisively improve the quality of the simulation and adapt it to the real conditions on the machine. In addition, you can use sim link as a data interface to match simulation and measurement data very easily by inserting the measurement data from the injection molding machine directly into the simulation software.
After initial sampling and further sampling, molds usually have to be returned to the moldmaker for reworking. With sim link, you can skip many cost-intensive optimization loops and transfer the set target values in the filling simulation directly to the injection molding machine at the push of a button.
The values determined in the simulation can be imported directly into the machine control of your injection molding machines with the help of sim link. Time-consuming and error-prone manual input of data at the machine is no longer necessary due to the data exchange between simulation software and injection molding machine.
Various subject matter experts are involved in the product development process. The simulation engineer is a specialist for filling the cavity(ies), the process engineer for machine settings. sim link simplifies the collaboration between simulation and production staff.
The Advantages of sim link at a Glance
Increases the quality of the simulation
The bonus of the data transfer between simulation software and injection molding machine: sim link offers the possibility to consider the dynamics of the machine selected for production. This allows you to decisively improve the quality of the simulation and adapt it to the real conditions on the machine. In addition, you can use sim link as a data interface to match simulation and measurement data very easily by inserting the measurement data from the injection molding machine directly into the simulation software.
Reduces the duration of the start-up phase
After initial sampling and further sampling, molds usually have to be returned to the moldmaker for reworking. With sim link, you can skip many cost-intensive optimization loops and transfer the set target values in the filling simulation directly to the injection molding machine at the push of a button.
Complete data consistency is ensured
The values determined in the simulation can be imported directly into the machine control of your injection molding machines with the help of sim link. Time-consuming and error-prone manual input of data at the machine is no longer necessary due to the data exchange between simulation software and injection molding machine.
Simplifies collaboration between departments
Various subject matter experts are involved in the product development process. The simulation engineer is a specialist for filling the cavity(ies), the process engineer for machine settings. sim link simplifies the collaboration between simulation and production staff.
 "Data Transfer Simulation and Injection Molding Machine | ENGEL")
How Does the Data Transfer Between Simulation Software and Injection Molding Machine Work?
sim link, as an interface for data exchange between the simulation program and the injection molding machine, works with the simulation programs Cadmould from Simcon and Moldflow from Autodesk. The parameters determined during the filling simulation can be transferred to a set-up data record and used directly on the injection molding machine. The values transferred from the simulation are converted into set-up parameters and checked for use on the injection molding machine. This initial set-up suggestion can be used immediately on the machine and makes a significant contribution to reducing multiple manual adjustments on the machine.
 "Johannes Kilian | ENGEL")
With ENGEL sim link, we close the gap between the digital twin of the mold and the real injection molding process. This allows you to significantly reduce iteration loops in the sampling process. During process adjustment, the know-how gained during simulation can be used easily and systematically.
Strong partners in the design process
sim link is compatible with the following simulation software tools
As a powerful software solution, Autodesk Moldflow® enables comprehensive injection molding simulations. The tool includes simulations for filling, holding pressure, warpage and cooling processes of various injection molding applications. These applications range from compact and 2-component molding to hybrid, internal gas pressure, foam, elastomer, silicone, and thermoset injection molding.
As an innovative solution for plastic injection molding simulation, CADMOULD enables the precise prediction and control of plastic behavior within the mold. Causes of problems such as air inclusions, weld lines or severe warpage can be reliably identified and addressed before production begins.
Moldex3D is the efficient 3D CAE software solution for designing and optimizing the injection molding process. It provides reliable, insightful, and precise results for component, tool and process optimization - from the first development step to final part production.
As a powerful software solution, Autodesk Moldflow® enables comprehensive injection molding simulations. The tool includes simulations for filling, holding pressure, warpage and cooling processes of various injection molding applications. These applications range from compact and 2-component molding to hybrid, internal gas pressure, foam, elastomer, silicone, and thermoset injection molding.
As an innovative solution for plastic injection molding simulation, CADMOULD enables the precise prediction and control of plastic behavior within the mold. Causes of problems such as air inclusions, weld lines or severe warpage can be reliably identified and addressed before production begins.
Moldex3D is the efficient 3D CAE software solution for designing and optimizing the injection molding process. It provides reliable, insightful, and precise results for component, tool and process optimization - from the first development step to final part production.
What our Customers Say About sim link
 "Gianluca Cappella | Intercable")
sim link helps to reduce the time needed to fine-tune the process parameters. The savings depend on the material type and part geometry and range from 10 to 50%.
 "Martin Hausbacher | Hagleitner")
We simulate almost every component, because this is the only way to get warpage and shrinkage under control, especially with PP housings.
