The Hybrid, High-speed Injection Molding Machine Ideal for Thin Wall Plastic Parts

e-speed Thin Wall Injection Molding Machine

Picture shows injection molding machine ideal for the production of thin wall plastic parts

The trend towards reduced wall thickness in packaging products is placing even greater demands on injection molding machines. The fast e-speed is our answer. It impresses with high performance on both the injection and clamping sides. Ensure profitable production of thin wall plastic parts, like thin wall plastic tubing or cups, with our e-speed.

Toggle lever

Type

Hybrid

Drive Type

< 6.500 kN

Clamping Force

The Thin Wall Injection Molding Machine for Plastic Parts in Use
  • Thin Wall Injection Molding with In-mold Labeling

    A 2-cavity mold for 1L pails with reduced wall thickness and IML shows what the hybrid machine e-speed 280 can do: Part weight reduced by 20% to just 30 g.

  • Production of Decorated Food Packaging

    On an e-speed 420/90 with in-mold labeling (IML), ready-to-fill margarine cups are produced automatically from polypropylene using the injection compression molding process.

  • Production of Cartridges with 1.2 mm Wall Thickness

    Cartridge molding requires high process dynamics and injection pressure. Label and finished part handling take place in a cycle < 13 sec. on the e-speed 500/90.

Picture shows Sales Manager Packaging at ENGEL Austria

Our e-speed is uncompromisingly designed for maximum performance. The e-speed easily achieves the highly profitable production of thin-wall containers with flow path/wall thickness ratios of greater than 400 at the shortest cycle times.

Ivica Puskaric, Sales Manager Packaging at ENGEL Austria
The Advantages of the e-speed Injection Molding Machine
Cycle time < 2 sec . and absolute cleanliness
Picture shows mold interior during the production of a thin wall plastic part

By avoiding oil mist formation and having a closed lubrication system, no dirt can get onto your products. In addition, the extra-stable clamping platens ensure excellent platen parallelism. Perfectly suited for a wide range of molds. All this with cycle times down to less than 2 seconds. Designed for the 24/7 production common in the packaging industry.

Reduced energy costs thanks to hybrid drive concept
Picture shows electric injection molding machine for thin wall injection molding

The hybrid drive concept reliably reduces any energy peaks thanks to kinetic energy storage. When the moving platen brakes, it absorbs the kinetic energy and releases it again when accelerating. Ideal for load-dependent electricity costs.

Specially designed for thin wall plastic injection molding
Picture shows production of thin wall plastic parts

The all-electric clamping unit combined with hydraulic injection is powered by large accumulators. The rapid acceleration ensures a maximum injection speed of up to 1,200 mm/s. Maximum injection pressure of well over 2,000 bar even with just a few cm of injection stroke. This enables reliable and complete filling of cavities for thin wall plastic parts – even with extreme flow path/wall thickness ratios.

Contact us

Do you have questions about the injection molding machine for thin wall plastic parts?

Additional Products And Services for the Production of Thin Wall Plastic Parts
Image shows networked injection molding machine from ENGEL

Digital Solutions

Our digital products and service solutions support you along the entire life cycle. From component design, through mold sampling and production, to maintenance and service.

Picture shows service technician from ENGEL

Service

ENGEL offers you service and spare parts management throughout the life of your machine. We support you from the installation of your machine and automation solution until the end of its service life.

Image shows injection molding automation solution from ENGEL

Automation

Expertise in injection molding automation at all levels. From the injection molding machine to the robot and conveyor belt system, to third-party peripherals. Everything from a single source.
